Vendor: LW Scientific

Revelation lll DIN, 4 Objective Microscope

$695.00 USD

Title: Revelation III-A DIN Achromatic. Monocular

Revelation III-A DIN Achromatic. Monocular Revelation III-A DIN Achromatic Trinocular Revelation III-A DIN PLAN Binocular Revelation III-A DIN PLAN Trinocular

Product variants

Low stock: 1 left

SKU: R3M-MN4A-DAL3

Quantity

Delivery times vary by product and destination. See our Shipping Policy.

Returns require a Return Authorization (RA) number and may be subject to restocking fees. See our Return & Refund Policy.

Compra 100% segura

Revelation lll DIN, 4 Objective Microscope

The Revelation III is a best-seller into physician and veterinarian clinics, as well as universities and medical schools. The Revelation lll comes with LED illumination, for daylight color, low heat, low power consumption, and super-long bulb life (30,000). Equipped for performance, its features include DIN achromatic or DIN Plan optics and a 30-year anti-fungal coating. The Revelation III is the choice for superior performance at a great value!

Head	Binocular (Seidentopf) Inclined 30°, rotates 360° Diopter adjustment 10X/18 wide field eyepieces (10X/20HP available) Monocular, trinocular, dual binocular and 45° sliding heads available Interpupillary distance range: Binoc head: 48-75mm Trinoc head: 55-75mm
Nosepiece	Quadruple forward-facing nosepiece Multiple ball bearing mounted
Objectives	DIN Achromatic or DIN Plan 30 year anti-fungal coating 4X, 10X, 40X, 100XR (oil) Parfocal, parcentric, color-coded
Stage	Mechanical stage (140mm x 130mm) Coaxial drive controls Range of traverse is 78mm x 50mm Stage locking lever Slow-close hydraulic slide finger
Focus	Coarse adjustment: range of 30mm Fine adjustment: graduation of 2μm Tension control knob
Illuminations	Moveable Abbe condenser, NA 1.25, rack & pinion Iris diaphragm 100-240V AC / 50-60Hz Auto-Switching Input Light Options: Variable LED light source (3W bulb)
Weight and dims	Height: 15” (380mm) Length: 9” (230mm) Width: 7” (178mm) Weight: 14 lbs. (6.4kg)

Title	Revelation III-A DIN Achromatic. Monocular, Revelation III-A DIN Achromatic Trinocular, Revelation III-A DIN PLAN Binocular, Revelation III-A DIN PLAN Trinocular
