Storing reagents in this filtering storage cabinet ensures clean lab environment for users.

Feel free to install the cabinet anywhere without any concern of your existing exhaust system.
Air purification inside the cabinet prevents heating and cooling loss caused by ducted air exhaust systems.

Specifications

Model		FSC-140	FSC-280
Internal volume (L / cu ft)		604 / 21.3	1317 / 46.5
Capacity (L or quantity of 1 L bottle)		140	280
Airflow rate (m3/min)		0.67	1.34
Noise level (dB)		< 50	< 55
Safety	Warning / Alarm	High Temperature, Door Open, Fan Fail, Sensor Error Check Filter, External Input Error
Safety	Protection	Over Temperature Protection, Over Current Protection
Dimension(W×D×H)	Internal (mm / inch)	930 x 636 x 1890 / 36.6 x 24.8 x 74.4	1868 x 636 x 1890 / 73.5 x 24.8 x 74.4
	External (mm / inch)	795 x 578 x 1315 / 31.3 x 22.8 x 51.8	1733 x 578 x 1315 / 68.2 x 22.8 x 51.8
	Drawer (mm / inch)	613 x 478 x 109 / 24.1 x 18.8 x 4.3	613 x 478 x 109 / 24.1 x 18.8 x 4.3
	Spill tray (mm / inch)	670 x 526 x 34 (1ea) / 26.4 x 20.7 x 1.3 (1ea)	670 x 526 x 34 (2ea) / 26.4 x 20.7 x 1.3 (2ea)
Weight (kg / lbs)		300 / 661.4	495 / 1091.3
Quantity of drawer (standard / max.)		5 / 10	10 / 20
Max. load capacity per drawer (L or quantity of 1 L bottle)		28	28
Max. load per drawer (kg / lbs)		40 / 88.2	40 / 88.2
Noise level (dB)		< 50	< 55
Electrical requirements (120V)		60Hz, 1.0A	60Hz, 2.0A
Cat. No.		AAHF1123U	AAHF1133U
