Ideal for professional use and higher education, the VE-S5 is an excellent tool in medical industrial research. A versatile device, useful in production procedures or quality inspection of industrial products, thanks to its zoom system.
Its Greenough design allows three-dimensional observation of insects. The VE-S5 is ideal in the dissection and classification of organisms in entomology and taxonomy, as well as the observation and selection of viable embryos in livestock.
WF 10X/20 mm
Variable Magnification Zoom System 0.7X, 0.8X, 1X, 1.5X, 2X,
Interchangeable 60mm / 2.3 “ diameter stage, opaque glass
Coarse anti-slip control knob.
|Transmitted and incident LED.|
|225 x 340 x 270 / 8.8” x 13.3” x 10.6”.|
110/240V, 50/60 Hz AC adapter.
|Trinocular head, inclined at 45 °. |
Stage with clamps.
Phototube with 23 mm diameter, compatible with VELAB MC,
LX series cameras and VE-SCOPEPAD tablet.
Two interchangeable plates: opaque glass, for transmitted light
and double-sided white / black, for incident light.
Interpupillary distance of 55 ~ 75mm.
Stable, robust, reinforced and easy to transport.
Lighting with independent switches.
Diopter adjustment in both eyepieces.
Anti-slip ring on lens and cap.
|Power cord |
