VE-S5C Binocular Stereoscope Microscope w/ integrated 1.3 MP camera and zoom (Intermediate)
The VE-S5C is the ideal for professional use in higher education, research and industrial procedures. It also comes equipped with a digital camera. A versatile device, useful in production procedures or quality inspection of industrial products, thanks to its zoom system.
Its Greenough design allows three-dimensional observation of insects and is ideal in the dissection and classification of organisms. The VE-S5 includes easy-to-use operational software compatible with Windows operating systems, perfect for the observation of images in real time and storage in a computer.
Eyepiece | WF 10X/20 mm. |
Camera | 3 MP, integrated. |
Objectives | 0.7X, 0.8X, 1X, 1.5X, 2X, 3X, 4X, 4.5X (7 to 45 total increases). |
Optical System | Greenough System, with variable magnification zoom. |
Stage | Interchangeable, translucent white and white / black. |
Focus | Coarse anti-slip. |
Ilumination | Trasmitted and incident LED. |
Dimensions | 225 x 355 x 270 mm/ 8.8” x 13.9” x 10.6”. |
Power supply | CA 110/240, 50/60 Hz. |
Main Features | Diopter adjustment on both eyepieces. Binocular head with interpupillary distance adjustment . Head inclined at 45 °. Stage with clips. Software for camera operating, capturing photo, video and digital analysis. Stative, robust, reinforced and easy to transport. Zoom adjustment knobs. Interpupillary distance of 55 ~ 75 mm. Integrated digital camera. Lighting with independent intensity adjustment. |
Applications | Education: Upper grade levels |
Accessories Included | USB cable Dust cover Software |
Warranty | 10 Years |
